AELAB Magnetic Hotplate Stirrers ASC-201
Features:
* LCD/LED Digital control of speed and temperature.
* Maintenance free brushless DC motor.
* RS232 interface enables data preservation and transmission and control through a PC.
* Speed setting range from 0-1500rpm.
* RS232 interface provides PC control and data transmission.
* Ceramic work plate with max. temperature of 340°C.
* Various optional accessories make it suitable for many applications.
* Hot warning safety indication on LED when the plate temperature exceeds above 50°C.
* PT1000 external temperature sensor for precise temperature control accuracy of ±0.2°C.
* LCD/LED Digital control of speed and temperature.
* Maintenance free brushless DC motor.
* RS232 interface enables data preservation and transmission and control through a PC.
* Speed setting range from 0-1500rpm.
* RS232 interface provides PC control and data transmission.
* Ceramic work plate with max. temperature of 340°C.
* Various optional accessories make it suitable for many applications.
* Hot warning safety indication on LED when the plate temperature exceeds above 50°C.
* PT1000 external temperature sensor for precise temperature control accuracy of ±0.2°C.
ASC-201
1
Quantity:
Magnetic Hotplate Stirrers ASC-201
These magnetic stirrers deliver powerful, smooth mixing and safe heating. These are useful in biological, physical, chemical, pharmaceutical laboratories, etc.
Features:
These magnetic stirrers deliver powerful, smooth mixing and safe heating. These are useful in biological, physical, chemical, pharmaceutical laboratories, etc.
Features:
- LCD/LED Digital control of speed and temperature.
- Maintenance free brushless DC motor.
- RS232 interface enables data preservation and transmission and control through a PC.
- Speed setting range from 0-1500rpm.
- RS232 interface provides PC control and data transmission.
- Ceramic work plate with max. temperature of 340°C.
- Various optional accessories make it suitable for many applications.
- “Hot” warning safety indication on LED when the plate temperature exceeds above 50°C.
- PT1000 external temperature sensor for precise temperature control accuracy of ±0.2°C.
Technical Specifications:
| Model | AHO-101 | AHO-102 | ASC-201 | ASC-202 | |
| Type | Hotplate Stirrer | Hotplate Stirrer | Stirrer | Hotplate Stirrer | |
| Work plate dimension | φ135mm(5 inch) | ||||
| stainless steel cover with ceramic | |||||
| Motor type | Brushless DC motor | ||||
| Motor rating input | 18W | 5W | |||
| Motor rating output | 10W | 3W | |||
| Power | 550W | 515W | |||
| Heating output | 500W | ||||
| Voltage | 100-120/200-240V 50/60Hz | ||||
| Stirring positions | 1 | ||||
| Max. stirring quantity[H2O] | 20L | 3L | |||
| Max. magnetic bar[length] | 80mm | 50mm | |||
| Speed range | 100-1500rpm | 0-1500rpm | 200-1500rpm | ||
| Speed display | LCD | Scale | LED | ||
| Temperature display | LCD | Scale | LED | ||
| Heating temperature range | Room temp.-340°C, increment 1°C | Room temp.-280, increment 1°C | |||
| Temperature control accuracy | ±1°C(<100°C),±1%(>100°C) | --- | ±1°C(<100°C) ±1%(>100°C) | ||
| Over temperature protection | 420°C | 320°C | |||
| Temperature display accuracy | ±0.1°C | ±0.1°C | ±0.5°C | ±1°C | |
| External temperature sensor | PT1000 (accuracy ±0.2) | ---- | PT1000 (accuracy ±0.2) | ||
| "Hot"warning | 50°C | 50°C | - | 50°C | |
| Data connector | RS232 | RS232 | - | RS232 | |
| Protection class | IP42 | IP42 | IP42 | IP21 | |
| Timer function | - | 1min to 99h 59min | --- | --- | |
| Dimension[WxDxH] | 160×280×85mm | ||||
| Weight | 2.8kg | ||||
| Permissible ambient temperature and humidity | 5-40°C, 80%RH | ||||
