AELAB Illumination Incubator AE-GZX Series
Multi-function incubator, which can simulate the natural light situation and it is applied for the following cases such as botanic growth tissue culture experiment for seeds in bud,botanic planting,insect and puppy breeding,microorganism and antibiotic culture, storing and the others constant temperature and luminous test.
AE-GZX-150 AE-GZX-250 AE-GZX-350 AE-GZX-450 AE-GZX-600 AE-GZX-800 AE-GZX-1000
1
Quantity:
Illumination Incubator
Multi-function incubator, which can simulate the natural light situation and it is applied for the following cases such as botanic growth tissue culture experiment for seeds in bud,botanic planting,insect and puppy breeding,microorganism and antibiotic culture, storing and the others constant temperature and luminous test.
Features:
Multi-function incubator, which can simulate the natural light situation and it is applied for the following cases such as botanic growth tissue culture experiment for seeds in bud,botanic planting,insect and puppy breeding,microorganism and antibiotic culture, storing and the others constant temperature and luminous test.
Features:
+It is the double screen and high luminance charactron display
+It has the timing device,which can be used for timing setting.
+Programmable luminescence controlling system is available, subsection controlling can be achieved.(five sections luminescence controlling)
+Independent ultra-high temperature protection equipment and working state hint make the user more safety and reliable.
+Use of environmentally friendly cfr-free refrigeration cooling airflow.
Technical Specifications:
#illumination
#american incubator
#detail incubator
Technical Specifications:
| Model | AE-GZX-150 | AE-GZX-250 | AE-GZX-350 | AE-GZX-450 | AE-GZX-600 | AE-GZX-800 | AE-GZX-1000 |
| Workvoltage (V) | AC110V 60Hz/AC220V 50Hz | ||||||
| Range of temperature control (°C ) | 5~50 (Without Illumination) 10~50(Without Illumination) | ||||||
| Timing scope ( min ) | 0-99.99 | ||||||
| Wavedegree of Temperature (°C) | ±1 | ||||||
| TemperatureResolution | 0.1 | ||||||
| Illumination (LX) | 0-12000 | ||||||
| Power (KW) | 1 | 1.5 | 2 | 2 | 2.5 | 2.7 | 3 |
| Cubage (L) | 150 | 250 | 350 | 450 | 600 | 800 | 1000 |
| Inner wall size ( H x W x D ) ( mm ) | 750x500x500 | 1000x500x500 | 1000x600x600 | 1000x650x700 | 1000x650x1000 | 1250x650x1000 | 1250x60x1250 |
| Overall dimension ( HxWxD ) ( mm ) | 1255x680x645 | 1595x680x680 | 1600x795x780 | 1620x920x855 | 1620x920x1155 | 1870x920x1155 | 1870x920x1405 |
| Shelf Load ( KG ) | 15 | 15 | 18 | 15 | 15 | 15 | 15 |
| Maximum Number of Shelves | 7 | 12 | 12 | 15 | 15 | 15 | 15 |
| Shelf Temperature ( mm ) | 60 | ||||||
| NW/GW(KG) | 100/142 | 123/173 | 196/203 | 160/200 | 180/230 | 200/260 | 230/290 |
