AELAB Horizontal Laminar Flow Cabinet AE-H1300 AE-H1800
+LCD Display
+Waterproof Socket
+Gas Tap
+UV Lamp
+Side Glass Window
AE-H1300 AE-H1800
Quantity:
AELAB Horizontal Laminar Flow Cabinet
LCD Display
Airflow velocily, UV timer, UV work time, system work time, real time.

Waterproof Socket
2 waterproof sockets are located in the side panel, for optimum convenience
of using small devices inside the cabinet.


Gas Tap


UV Lamp
Emission of 253.7 nanometers for most efficient decontamination



Side Glass Window
The transparent side glass windows maximize light and visibility
inside the cabinet, providing a bright and open working environment.

TECHNICAL PARAMETERS
ModelAE-H1300AE-H1300
External Size (W*D*H)
Internal Size (W*D*H)
1300*820*2040mm
1200*500*570mm
1800*820*2070mm
1700*500*570mm
Work Surtace Height
Display
Airflow Velocity
750mm
LCD Display
Average of 0.3-0.5m/s
MaterialMain Body: Cold-rolled steel with anti-bacteria powder coating
Work Table: 304 stainless steel
Side and Front Window: 5mm toughened glass, anti-UV
Pre-Filter
HEPA Filter
Polyester fiber, washable
99.999% efficiency at 0.3μm
Noise
Front Window
<60dB
Motorized
Max Opening
LED Lamp
430mm
12W*1

16W*2
UV Lamp30W*1
Emission of 253.7 nanometers
30W*1
Consumption
Waterproof Socket
400W
Two, total load≤500W
700W
Caster
Power Supply
Universal caster with leveling feet
AC220V+10%50/60Hz; 110V+10%60Hz
Standard Accessory

LED lamp, UV lamp*2, Base stand, Gas Tap, Waterproof socket*2
Water tap(only for AE-H1800)
Gross Weight
Package Size(W*D*H)
254kg
1450* 1060*1650mm
328kg
1950* 1060* 1600mm
