Model

AE-POWER300

AE-POWER600

AE-POWER600i

AE-POWER600K

Voltage

5-300V

5-600V

5-600V

5-600V

Current

1-500mA

1-500 m A

1-300m A

1-1000 m A

Power.

1-150W

1-300W

1-180W

1-300W

constant voltage, constant current and constant power

Yes

Micro-current state function

Yes

Timer

1min-99h59min

Pause / Resume function

Yes

Microcomputer switching power supply

LCD

Display

Yes

Programmable method

Yes

Stores single-step 12 program

Yes

Automatically generates

Yes

Leakage protection

Yes

Automatic recovery after power failure

Yes

The monitoring of over-voltage, arc,

no-load, mutation load, overload and short circuit

Yes

Operating environment

Temperature 0-40 °C, Humidity 0-95%

4 jack on the parallel

Yes

Input voltage

90-260VAc , 50/60Hz

Dimensions (L×W×H)

33×22×8cm

Net weight

3.5Kg

#electrophoresis and poweAr supplyModel

AE-Power600h

AE-Power3500

AE-Power500HC

Voltage

5-600V

5-3500V

10-500V

Current

1-1000 m A

1-400mA

0.01-3.0 A

Power

1-300W

1-400W

1-500W

constant voltage, constant current and constant power

Yes

Microcomputer switching power supply

Yes

Timer

1min-99h59min

Pause / Resume function

Yes

Display

LCD

High-resolution backlit,

128 × 64 pixel graphical LCD

Programmable method

Yes

Can store 12 programs

Yes

Automatically generates

Yes

Micro-current state

Yes

--

Leakage protection

Yes

Automatic recovery after power failure

Yes

The monitoring of over-voltage, arc, no-load,

mutation load, overload and short circuit

Yes

Operating environment

Temperature 0-40 °C, Humidity 0-95%

4 jack on the parallel

Yes

Input voltage

90-260VAc  50/60HZ

Dimensions (L×W×H)

32×22×8cm

32×27×10cm

Net weight

3.5Kg

4.5Kg
