AELAB Dissolution Tester
Dissolution tester is used for detecting pharmic dissolution from tablet, capsule etc. in prescriptive menstruum.
AE-RC-1 AE-RC-3 AE-RC-6 AE-RC-8
Quantity:
Dissolution Tester
Dissolution tester is used for detecting pharmic dissolution from tablet, capsule etc. in prescriptive menstruum.
Features:
+ Auto-diagnose , auto-alarm.
+ Stainless steel basket and paddle.
+ Micro processor and LCD Display.
+ The head part of the instrument can be turned over smoothly and flexibly(Rise and fall for AE-RC-8) .
+ Water circulating in the bath to keep the temperature conformity with magnetic pump.
Model | AE-RC-1 | AE-RC-3 | AE-RC-6 | AE-RC-8 |
Basket | 1pc | 3pcs | 6pcs | 8pcs |
Speed Range | 20~200rpm | |||
Speed Precision | ±2rpm | |||
Temp. Range | RT +45.0℃ | |||
Temp. Precision | ±0.3℃ | |||
Timing Range | 5~900min | 5~900min | 1~999min | 1~999min |
Time Precision | ±0.5min | |||
Working Time | >24h | |||
Paddle Swing Amplitude | ±0.5mm | |||
Basket Swing Amplitude | ±1.0mm | |||
Power Consumption | 600W | 1200W | ||
Power Supply | AC110/220V±10%, 50/60Hz | |||
External Size(W*D*H)mm | 260*300*480 | 510*300*480 | 960*320*480 | 680*540*480 |
Package Size(W*D*H)mm | 560*410*590 | 780*420*560 | 1230*510*590 | 1010*680*580 |
Gross Weight(kg) | 18.5 | 28.5 | 47 | 91 |
